 Wireless control, command and monitoring





937446 Solar Transmitter  Please request price






937444  Please request price




Performance

5 Miles ( 8 km ) line of sight
Optional extended 20 Miles (32 km) line of sight
Features:
High and Low Level remote indication
Low battery status indication or alarm


Operation Command, Manual or Automatic

Manual: Pump manually controlled by the operator
Automatic: The tank level sensor provides the remote command to start or stop the operation.
Monitoring:
Blue light indicates the pump status
Red light indicates the tank level is low
Green light indicates the tank level is high
Yellow light indicates low battery (solar) 937446



   COMPONENTS:

   1  Base Transmitter w dry contact inputs
   1  Base Receiver pre-wired,  ( Command Center )
   2 Antenna 36 inch with coaxial cable & PL259 connector
      NEMA 4  ABS plastic enclosure, & wiring diagram

 SPECIFICATIONS:

 Wiring Diagram

Operating Voltage: 12  VDC
Temperature: -4 to +140 F (-20 to +60 C)
Receiver Type: 16 BIT Digital -118 dB
Carrier Frequency 27 MHz  Free license industrial band
 Codes: DIP switch programming
Current Drain Receiver  25 mA, standby, 65 mA operation
Transmitter 2 A. 1 second
Data Input TX  2 Dry contacts
Relay Output RX 10 Amp max  250VAC N/O  class 2 pilot duty
Antenna Imp 50 Ohms Quarter Wave Antenna optional
Dimensions: 11.81 x 7.87 x 6.29 in. / 299.97 x 199.90 x 159.77 mm
Weight 8 lb. (4 Kg) each
Enclosure  NEMA 4,  IP67  ABS plastic  waterproof
Compliance per FCC Part 15.249,  50mV/m @ 3m
  Circuit board UL796 and UL94

 SPECIAL FEATURES:

Receiver incorporates:
Selector switch:   Hand, Off and Auto
LED light indicators for tank level and pump status,
The solar Transmitter 937446 also includes,
One Solar Panel 30W, Charge controller & 7.2 Ah battery




 Wireless Selection


Long Range Wireless Componebts   Medium Range

937000   1 & 4 channel   Specifications

Wireless I/O Modular  Specifications

938000  1, 2 & 4 channel  Specifications
