     Antennas

  27MHz Whip Antenna









8 inch Whip short range

Frequency 26-28 MHz
Gain 0 dBi
Vertical Beam 20 degrees
Impedance 50 Ohms
Adapter included BNC/
PL-259
Max Power 50 Watts
VSWR < 3:1 avg.
Polarization Vertical
Wind Data 100 mph

 937088    $39.99




   27MHz Omni Antenna  36 inch

          Quarter Wave (3 foot)

Frequency 26-28 MHz
Gain 3 dBi
Vertical Beam 30 degrees
Impedance 50 Ohms
Connector SO-239
Max Power 150 Watts
VSWR < 1.5:1 avg.
Polarization Vertical
Wind Data 150 mph

12 Feet of 50 ohm coaxial cable,
connectors
and mounting kit

 937099  $89.99
   27MHz   12 inch Omni Antenna Magnetic Base




Frequency 26-28 MHz
Gain 2 dBi
Vertical Beam 27 degrees
Impedance 50 Ohms
Connector PL-259
Max Power 100 Watts
VSWR < 1.5:1 avg.
Polarization Vertical
Wind Data 150 mph

10 Feet of 50 ohm coaxial cable,


 937089 Omni Magnetic   $59.99



  150MHz  2 Meter   Omni Antenna ( 5/8 )








Frequency 140-170 MHz
Gain  4.5 dBi
Overall Length 67 inches
Impedance 50 Ohms
 Connector SO-239
Max Power 150 Watts
VSWR 5MHz < 1.5:1 avg.
Polarization Vertical
Wind Data 150 mph

12 Feet of 50 ohm coaxial cable,


Transmission Pattern

931487    $179.99




   150MHz  2 Meter Omni  High Gain ( 7/8 )

Frequency 144-170 MHz
Gain  6.7 dBi
Overall Length 126 inches
Impedance 50 Ohms
Connector SO-239
Max Power 200 Watts
VSWR  5MHz < 1.5:1 avg.
Polarization Vertical
Wind Data 150 mph

12 Feet of 50 ohm coaxial cable,


Transmission Pattern

931490   $199.99
   150MHz  2 Meter  3 Element Yagi Antenna






Transmission Pattern

Frequency 150-174 MHz
Gain 9.2 dBi
Overall Length  42 inches
Vertical Beam 57 degrees
Impedance 50 Ohms
Connector SO-239
Max Power 200 Watts
VSWR < 1.5:1 avg.
Polarization Linear
Wind Data 150 mph

12 Feet of 50 ohm coaxial cable,


931503 Yagi   $279.99



    433 MHz Antennas


938432  3 Element Beam  Yagi



433 MHz, Gain: 7 dBi
Rating: 150 Watts
Impedance 50 ohms N terminal
Vertical beam 45 degrees
Horizontal beam 60 degrees
With 12 inch Coax
Base Length: 18", Weight: 1.0lb

938432    $179.99





    938433  12 Element Beam  Yagi



433 MHz, Gain: 14 dBi
Rating: 150 Watts
Impedance 50 ohms
N terminal
Vertical beam 42 degrees
Horizontal beam 45 degrees
With 12 inch Coax Cable
Base Length: 64", Weight: 5.0lb

938433   $369.99





    938450    37 inch Omni Base





433 MHz, Gain: 3 dBi
Rating: 250 Watts
Impedance 50 ohms
N terminal,
Vertical beam 45 degrees
 Length: 37", Weight: 3.0lb

938450    $259.99




938092 OMNI DIRECTIONAL  3 dBi



14" Omni Antenna 938092

433 MHz, 3dBi  gain,
Impedance 50 ohms Magnetic base
With 120 inch (3M) Coax Cable
and SMA m connector

938092    $39.99






 938610 Coaxial Cable

10 Feet RG58 Coax with N Male
    and SMA Male

 938610     $69.99




 938630 Coaxial Cable

30 Feet RG8 Coax with N Male
    and SMA Male

 938610     $159.99
