Long Range Directional Antenna Kit

Model: 937098

. Special Order

Compatible products

	1 Channel Transmitter
	4 Channel Transmitter
	2Ch Handheld Transmitter
	4Ch Handheld Transmitter
	AC Adapter

Directional Long Range Antenna

Specifications
Antenna Impedance: 50 Ohms. Wind load 100 MPH.
Yagi 4 Element / 11 Meter "Maximum" Beam MAC 16' Gain: 14db
Turn Radius: 13' Power Multiplication: 28x Front to Back Separation: 29db Stack.

Antenna distance calculator

   Total Antenna Height of 1st Station
   Total Antenna Height of 2nd Station
  Feet Meters

For the 1st station, the Radio Horizon is away.
For the 2nd station, the Radio Horizon is away.
The total line of sight distance is Miles Km.
